NanoBanner
Mobile LED DisplaysRoll In, Not Roll Up
Retail, exhibition and lobby signage for wayfinding or promotional content has long relied upon, printed, roll-up banners that quickly become outdated and can fade, wrinkle or tear over time.
NanoBanner LED displays modernize and expand the convenience of legacy static pop-up banners, offering organizations a fully integrated digital signage experience in a similarly tall, portrait orientation form factor. NanoBanner is ideal for bright, colorful and motion-based content, has a built-in rolling base for mobility and is plug-and-play for easy content updates.
Forget faded, static banners. Unshackle creativity and bright, motion graphics with NanoBanner.
Connect & Scale
Removable trim enables combining 2, 3, 4 or 5 NanoBanner units together
to form a seamless mobile video wall as large as 138" diagonal.
Multi-Device Control
Easily load content from a PC, smartphone or tablet using Wi-Fi, a Local Area Network or USB drive.
Ultra Slim
With a 1.5” profile frameless design you can easily roll it into any tight space. Or mount it to a wall or hang it from the rafters with third-party mounting solutions.
Versatile Playback
Supports real-time synchronous and offline playback for diverse commercial and event scenarios.
Why NanoBanner
GOB Protective Coating
Glue-On-Board (GOB) architecture enhances LED durability against bumps and bangs in high-traffic applications such as retail stores, corporate lobbies, tradeshow exhibits and more.
Rolling Base
With a built-in cart featuring locking wheel brakes, NanoBanner is quick to set up at the start of the day and put away at close. Just roll up and plug in.
High Visibility
With pixel pitch options that support comfortable viewing from as close as 8 feet and brightness as high as 800 nits audiences clearly see content day or night.
NIXEL™ to Pixel Warranty
Your display is engineered to pass the ultimate test: time. We use high-performing materials to ensure NanoBanner is a worthwhile investment. Our warranty coverage starts pixel one, ensuring your display is covered 100%.
High Durability
Easy Mobility
Comfortable Viewing
Robust Warranty
| Model | NanoBanner 1.5 | NanoBanner 1.9 |
|---|---|---|
| Pixel Pitch | 1.5 mm | 1.9 mm |
| Brightness | 550 nits | 800 nits |
| Resolution | 384 x 1080 | 320 x 900 |
| Power Consumption (Max./Avg.) | 460/142 W | 425/142 W |
| LED Technology | SMD | |
| Refresh Rate | 3840 Hz | |
| Overall Dimensions (W x H) | 24.6 in x 75.2 in. / 624mm x 1910mm (including base) | |
| Display Size (W x H) | 24.02 in. x 67.52 in. / 610mm x 1715mm | |
| Viewing Angle Max {3} | 178° horz / 178° vert | |
| Weight (excluding base) | 83.8 lbs / 38kg | |
| Working Voltage | AC100-240V 50/60Hz | |
| Maintenance Access | Front | |
| Protective Coating | Glue-On-Board (GOB) | |
| Ingress Protection Rating | IP30 | |
| Operating Temperature/Humidity | 14º ~ 104º F / -10 ~ 40 C, 10 ~ 80% | |
| Installation Mode | Rolling Base (included) / Hang / Wall Mount | |
Documents & Downloads
Specification Sheet
